The heatcutting machine model HSG-L-M operates from roll to roll. A rubber coated conveyor roll pulls the fabric from the bale, the cloth then moves on to a ceramic cutting base (ceramic tubes) is separated by a hot blade and is immediately expanded after the separatioin by 2 motor-driven rubber rollers to avoid Re-fusing of the separated edges. The separated material is then rolled on 2 friction shafts.
Type HSG-L-M
Block "product-contact" not found
Categories: HSGM, Therm Cutting Machines longitudinal
TECHNICAL DESCRIPTION
Fabric width: | 1,2 – 1,5 – 1,8 – 2,2 – 3,0 m | |
Minimum width to be achieved: | 10mm – with blade holder E-10 | |
Cutting element: | electric heating blade | |
Temperature: | 100-700°C, infinitely variable and stabilization of the present temperature | |
Cutting spots: | 10 – 20 – 30 – 40 – 50 – 60 (and more on special request) | |
Cutting speed: | depending on fabric, weight and type of blade up to 100 m/min | |
Max. diameter of fabic roll for dewinding: | 500 mm, with adjustable brake system | |
Max. diameter of fabric roll for rewinding: | 500 mm, through adjustable pneumatic friction | |
Accessories: | edge controlling system, rotary stretcher, selvedge exhauster, speed indicator |
