FUNCTION:
１．Eliminate the pin-hole appearance caused by traditional sewing machine, water tight is achieved for non-woven, water and air tight can be achieved for thin plastic film.
２．By using vibration to creat friction heat for melt and cutting without smoke, without extra ordinarily flavor, eliminate the dangerous and air pollution
３．Oscillate 20,000 times per second, preheat is not needed easy operation, continuous operation, fast, efficient, low labor cost.
４．By replacing roller can make various shape of design, high-accuracy
５．Stainless steel of adjustable feeding guide plate. variable width from 28 mm ~ 67 mm.
６．High output by ultrasonic generator, high efficiency, low temp of horn, steady machine suitable for continuous procession of heat plasticity
７．The roller’s life could stay long, and very precise.
APPLICATION :
filter、dust-proof non-woven fabric、mask、backpack、tent、umbrella、raincoat、Bath curtain、fitted sheet、chair cover、clothes、toy、hair ornaments、ribbon、Ribbon flower、Christmas decoration、decoration、lampshade ….etc.
SPECIFICATION:
1.ELECTRIC SOURCE : 220V, 6A, 60 Hz
2.MACHINE DIMENSION : W1200 × L550 × H1100 mm
3.POWER OUTPUT : 1500W MATERIAL / THICKNESS0.03 ~ 2.0 mm (20KHz 2500W, 35KHZ 1000W are optional)
4.OPERATION FREQUENCY : 20 KHz
5.MOTOR : 40W × 2
6.WELDING SPEED : 0 – 18M / min
7.MACHINE NET WEIGHT : 120 kg
8.WELDING WIDTH : 1.0 – 48mm (76,100 are optional)
